Bachmann Twist 2S 2x power socket stainless steel (931.000)
The Bachmann Twist 2S 2x power socket stainless steel (931.000) is a power strip for office, lounge and kitchen areas. With its compact design and low installation depth, it is easily integrated in desks or kitchen worktops
Bachmann Twist 2S 2x power socket stainless steel (931.000)
TWIST is a power strip for office, lounge and kitchen areas. With its compact design and low installation depth, it is easily integrated in desks or kitchen worktops. Because the power cable is routed close to the housing, the installation depth is only around 40 mm, so the unit can be easily installed above a drawer.
With a stainless steel look finish, the TWIST blends easily into both modern and organic interiors. After use, simply rotate the cover and the socket outlets disappear underneath it. The TWIST won the Red Dot Product Design Award 2012.
Advantages:
- Very low installation depth (approx. 40 mm)
- Compact design (H x diameter: approx. 42.5 x 115 mm)
- Space-saving cable routing
- Quick and easy to install
- Finish: Stainless steel
- Red Dot Product Design Award Winner 2012
Key Features:
- 2x socket outlets with earthing contact, child-proof, black
- Installation diameter 105 mm, installation depth 40 mm
- for desk or table top thicknesses of 20 mm to 40 mm
- Metallic stainless steel look cover disc
- power input: 2.0 m cable with end sleeves
- black earthing contact mounting plug (included)
Note DGUV V3: According to DGUV V3, permanently screwed / stationary power strips must be checked every 4 years by a qualified electrician in accordance with DIN VDE 0100-600. Portable power strips must be checked annually. Further information can be found in the download area under "Manufacturer's declarations"
| Product sheet: |  [pdf, 365 kb] |
|---|---|
| Technical drawing: | [pdf, 68 kb] |
| RoHS / REACH: | [pdf] |
| Installation manual: | [pdf, 250 kb] |
| Warning/safety instructions: | [pdf] |
| Contains installation material: | + |
| Manufacturer/Importer: | Bachmann GmbH, Ernsthaldenstr. 33, 70565 Stuttgart, info@bachmann.com |
| Number of sockets: | 2 |
| color: | Stainless Steel |
| Form: | rund |
| Land: | Germany |
| screw-on: | Yes |
If warning and safety instructions are to be observed for a product, these can be found in the respective installation instructions or in a separate PDF, depending on the manufacturer. Available documents for the product can be found in the available PDF files (see above).
