Bachmann TWIST 2 1x FR socket UTE 1x USB charger A/C, GST18, round (946.014) silver
The Bachmann TWIST 2 built-in socket (946.014) in matt silver is a round built-in socket (1x UTE socket, 1x USB A/C charger) for the French power grid. Thanks to its compact design and low installation depth, it can be integrated into desks or kitchen worktops to save space. Supplied with 0.2m cable H05VV-F3G1.5mm² power input, GST18 plug black.
Bachmann Twist 1x socket, 1x USB Charger 931.231 white matt
The Bachmann Twist 1x socket, 1x USB Charger 931.231 white matt look is a socket unit for office, lounge and kitchen. Thanks to its compact design and low installation depth, it is integrated into desks or kitchen worktops to save space. The power line is routed close to the housing, so that the installation depth is only about 40 mm - installation via drawers is thus easily possible.
Due to the stainless steel look, the Bachmann TWIST 931.231 fits into modern as well as organic, lively form and color concepts. Clever is the closure: after use, the cover is rotated - the sockets disappear underneath.
Key features Bachmann Twist 1x socket, 1x USB Charger 931.231
- Very small installation depth (about 40 mm)
- Dimensions (HxØ): 42,5x115 mm
- Installation diameter 105 mm, installation depth 40 mm
- Plate thickness: 20 to 40 mm
- Space-saving cable routing
- Material cover: metal
- Material socket: plastic
- 1 x earthing contact socket with child protection
- 1 x USB Charger
- Supply: 2,0 m
- Incl. Wire end ferrule and mounting plug
- Easy and quick installation
- Surface: white matt
- Integrated water drainage
Note DGUV V3: According to DGUV V3, permanently screwed / stationary power strips must be checked every 4 years by a qualified electrician in accordance with DIN VDE 0100-600. Portable power strips must be checked annually. Further information can be found in the download area under "Manufacturer's declarations"
Note DGUV V3: According to DGUV V3, permanently screwed / stationary power strips must be checked every 4 years by a qualified electrician in accordance with DIN VDE 0100-600. Portable power strips must be checked annually. Further information can be found in the download area under "Manufacturer's declarations"
| Product sheet: |  [pdf] |
|---|---|
| Technical drawing: | [pdf] |
| RoHS / REACH: | [pdf] |
| Installation manual: | [pdf] |
| Warning/safety instructions: | [pdf] |
| Packaging dimensions (LxWxH in mm): | 185 x 185 x 95 |
| Scope of delivery: | 1x TWIST2 incl. 2m cable with ferrules, 1x assembly plug, 1x assembly tool, 1x mounting plate for worktops from 6-24mm |
| Contains installation material: | + |
| Manufacturer/Importer: | Bachmann GmbH, Ernsthaldenstr. 33, 70565 Stuttgart, info@bachmann.com |
| Number of sockets: | 1 |
| color: | Silber |
| Form: | rund |
| USB-Charger: | USB A/C |
| Land: | France |
| screw-on: | Yes |
If warning and safety instructions are to be observed for a product, these can be found in the respective installation instructions or in a separate PDF, depending on the manufacturer. Available documents for the product can be found in the available PDF files (see above).
